Sandwich Panel Making Machine for Non - Combustible Decorative Materials

Sandwich Panel Making Machine for Non - Combustible Decorative Materials
Sandwich Panel Making Machine for Non - Combustible Decorative Materials Sandwich Panel Making Machine for Non - Combustible Decorative Materials Sandwich Panel Making Machine for Non - Combustible Decorative Materials Sandwich Panel Making Machine for Non - Combustible Decorative Materials

Büyük resim :  Sandwich Panel Making Machine for Non - Combustible Decorative Materials

Ürün ayrıntıları:
Place of Origin: China
Marka adı: chuangxin
Sertifika: CE
Model Number: XD-DB
Ödeme & teslimat koşulları:
Minimum Order Quantity: 1 set
Fiyat: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: L/C, T/T
Supply Ability: 50 Sets per year

Sandwich Panel Making Machine for Non - Combustible Decorative Materials

Açıklama
Product Name: mgo board machine Production capacity: 1222 Sheets
texture of material: steel Warranty: 1 years
Automatic grade: Automatic raw material: Mgo,mgcl,fiber glass mesh
Standard: CE type: free standing
Vurgulamak:

Construction Material Making Machinery

,

polyurethane sandwich panel machine

Sandwich Panel Making Machine for Non - Combustible Decorative Materials



factory distribution mgo board product line, magnesium oxide board machine



Composition



Raw Material Percentage(%)
MgO 48
MgCl2 32
Perlite 10
Fiberglass 2
Chip 6
Others 2
Product Description

Magnesium plate glass (commonly known as magnesium oxide board) is magnesium oxide,

magnesium chloride, and water ternary system, configured and made modifiers and processing,

stable performance magnesia cementitious material to neutralize alkaline fiberglass mesh to

 enhance the materials to lightweight materials for filler composite made of new non-combustible

decorative materials. Processed using a special production process, with a fireproof, waterproof,

odorless, non-toxic, ice-free, does not rot, does not crack, the same, non-flammable, high strength

and light weight, easy construction, long service life and etc.





Test properties:



Impact Resistance > 6 kJ/m2
Tensile Strength > 5.5 MPa
Density (Specific Mass) ~1000 Kg/m3 (+/-<2%)
Moisture Absorption ~26% max. saturation (slow absorption rate)
Moisture Content ~6%
Water Vapour Diffusion ~28 / 35
Specific Heat ~930 J/kgK
Thermal Conductivity ~0.44 W / mK
Modulus of elasticity ~6045 N/mm2
Flexibility
UNI E 12372
~20.1 N/mm2 maximum
12mm x 1220 x 2440 = 10 N/mm2
Surface Alkalinity ~10 Ph
Thermal Expansion Hot/Cold 0,01 mm/mC (from temp +20C to -20C)
Expansion in Water less than < 0.02% from ambient to saturation
Freeze / Thaw - UNI EN 520 100 cycles without notable effects
Frost Resistance no water drops form on surface
Combustibility / Fire Ratings non-combustible / 12mm exceeds 1 hr fire rating
Dimensional tolerance thick 0.2mm / width 2mm / length 3mm / Sq 3mm
Toxicity Pollutants Heavy Metals - UNI EN 12457-2 Below measurable levels of test instruments
Asbestos Analysis Absent - not measurable
Formaldehyde Analysis Absent - not measurable
Sound Attenuation (9mm) tested design ASTM E90 = STC 48, 50, 55, & 60
Color Slate Grey and Chalk White
Surface texture smooth one side; uniform machine textured back
Basic Compounds (MgO)+(natural silicates)+(glass fibre)+(wood fibre)



 Sandwich Panel Making Machine for Non - Combustible Decorative Materials 0Sandwich Panel Making Machine for Non - Combustible Decorative Materials 1
