Light Weight Fiber Cement Door Production Line with Fully Auto Mixing System

Light Weight Fiber Cement Door Production Line with Fully Auto Mixing System

    • Light Weight Fiber Cement Door Production Line with Fully Auto Mixing System
    • Light Weight Fiber Cement Door Production Line with Fully Auto Mixing System
    • Light Weight Fiber Cement Door Production Line with Fully Auto Mixing System
    • Light Weight Fiber Cement Door Production Line with Fully Auto Mixing System
  • Light Weight Fiber Cement Door Production Line with Fully Auto Mixing System

    Ürün ayrıntıları:

    Place of Origin: China
    Marka adı: chuangxin
    Sertifika: CE
    Model Number: XD-1

    Ödeme & teslimat koşulları:

    Minimum Order Quantity: 1 set
    Fiyat: negotiation
    Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
    Delivery Time: 30 working days after received your payment
    Payment Terms: L/C, T/T
    Supply Ability: 50 Sets per year
    Şimdi başvurun
    Detaylı ürün tanımı
    Product Name: Building Moulding Board machine Production capacity: 2500 Sheets
    texture of material: steel Warranty: 1 years
    Automatic grade: Automatic raw material: Mgo,mgcl,fiber glass mesh
    Standard: CE type: free standing

     Light Weight Fiber Cement Door Production Line with Fully Auto Mixing System



    top factory automatic  fiber cement door making production line for china good machine



    Hi-tech mgo gypsum board production line  is our company new product developed successfully referring to advanced technology and experience from home and abroad.

    It is the great invention of the exterior insulation board realizing industrial production, and we have applied for many national patents.

    Hi-tech mgo gypsum board production line  consists of 3 parts:

    1. Fully-auto mixing system

    2. Automatic board-making machine

    3. Automatic cutting saw

    Advantages

    Number

    Item

    Content

    1

    Low cost

    Low labour and material costs

    2

    Long life

    Up to 30 years

    3

    Recycling use

    Reused for more than 10 times

    4

    Flexible layout

    Layout adjusted according to your requirement

    5

    Environment protection

    Environment-friendly materials used

    6

    Safe & Stable steel structure

    Earthquake proof & Wind resistance



     Light weight



    · Good sound insulated



    · Heat Insulated



    · Waterproof/ Water fast : Near about 0% moisture absorption.



    · Fire proof.



    · Energy Efficient



    · Environmental, Ecofriendly.



    · Civilized and convenient construction



    Our Services
    1. Low price and superior quality no matter you are our new clients or regular;



    2.Good performance in marketing policy, quality, control, loading and shipment inspection,



       clearing custom documents, after service for previous clients;



    3.Professional foreign-trade salesman serving for you.







    If you have any questions,please feel free to contact us,best service is always there for you



     Magnesium Oxide Board Machine with fashionable design, reasonable structure, stable running manufactured board of even thickness in large production once through double- roller-extruding technology. This production line is equipped with shaking device which remove inside and outside air bubble, so our board is more compact. In addition, we use the no-woven cloth as the separating film to increase the toughness and strength of the board. The machine can be adjusted arbitrarily, and then produce the board with the thickness of 2-60mm, the biggest width of 1, 300mm and unlimited length. So you can adjust the thickness of board at will.

    At the end of 21st century, many cities in China were implementing new rural construction, almost at the same time, our country put forward Western development plan, fiber cement board has been developed rapidly because of its own high quality, the support of the state government policy, the rapid rising of boards demanding. And fiber cement boards have the advantages of protection against mould, insects and termites, water resistant, anti-aging and etc, and the development space of it will be infinitely wide. fiber cement production line

    2-    panel machine is a movable producing panel machine which need platform to move during producing.



    3-  Thin steel wire is put inside the panel in advance before producing. And this process is easy, not using tensile machine.



    4- The machine is applied to the high tech. Extrusion technique can make the panels more density and surface much smoother.

    Providing overall solutions about mgo board, EPC project, seperate machinery, products export. Including technology design, manufacturing, installation,commissioning, training, service, etc.



    Outline.Length: 18m width: 1.5m

    Output: 1800peices per day (8 working hours).

    Operator: One production line needs 15-18 workers.

    Specification of board: 3,4,5,6,8,9,10,12,15mm thickness.

    This production can produce two kinds of MGO board: common MGO board and coated MGO board.

    Such board making machine has one 3KW timing electromotor and one 2.2KW electromotor.


     After-sale
    After purchased the equipment, we will teach relevant technology for free, and will go to your factory for installation and testing until you can produce the qualified product by yourself. Our company will train 2-3 technical personnel for free until he can get the skill. We will take responsibility for provide technical consultation and following-up service for a long time, the equipment warranty period is one year.





    1. We offer Technical Support until the workers know how to operate.



    2. We provide free answers about all kinds of questions about the production,if   necessary,pls call us freely.



    3. We provide lifelong guidance about our equipment.visit client in regular times.



    4. Provide equipment easy-broken pasts year in year.to insure your machine can working continuously.





    Test we can do before delivery:


    Fireproof board test report
    Test standard: JC688_2006 < MGO board standard >
    Specification 10mm Produce date 2014.08.06 Test date 2014.09.01
    Test item Technical requirement Test results Results
    Density (t/m 3 )

    1.0 Qualified
    Bending strength(MPa) ≥10 14 Qualified
    Impact strength
    (KJ/M2)
    ≥2.5 6.5 Qualified
    Moisture resistance No moisture No moisture Qualified
    Water content (%) ≤8 5.7 Qualified
    Contraction rate when heated (%) ≤0.3 0.10 Qualified
    Expansion when put into water (%) ≤0.6 0.13 Qualified
    Water absorption (%) ≤28 10 Qualified
    Crisp coefficient ≥0.7 1.3 Qualified
    Warp when heated (‰) ≤3(Corporation standard ) 0.12 Qualified
    Put out of nails E<6 6<e<10
    E >10
    25 Qualified
    ≥25 ≥20 ≥15

    mgo board machinemgo board production line

                                Light Weight Fiber Cement Door Production Line with Fully Auto Mixing SystemLight Weight Fiber Cement Door Production Line with Fully Auto Mixing System



    Magnesium oxide board have been used primarily as fireproof materials for walls and ceilings in office buildings, apartment complexes, residential constructions, hotels, theatres, restaurants, railway stations, airports, scientific research institutions, schools, hospitals, and stadiums. Some patterned products have been used as decorative boards.

    It also can be used as an interlayer for building, movable partitions, sound-absorbing structures, sound insulation structures, heat insulation and preservation structures, sign boards, fireproof partition walls, low fencing partitions, fireproof pipeline, fireproof doors, cornice baffle boards, public restroom dividers, baseboards, truck cabinets and billboards etc.
